Copyright (C) 2000, 2001, 2002, Red Hat, Inc.

RAM: 0x00400000-0x007f4000, 0x00400000-0x007f4000 available
RedBoot> ip_address -h 192.168.1.17
IP: 192.168.1.16/255.255.255.0, Gateway: 192.168.1.1
Default server: 192.168.1.17, DNS server IP: 0.0.0.0
RedBoot> load -r -b 0x400000 aki3068net-image.bin
Using default protocol (TFTP)
Raw file loaded 0x00400000-0x00552dd3, assumed entry at 0x00400000
RedBoot> exec -c console=ttySC1,38400
Now booting linux kernel:
Entry Address 0x00400000
Cmdline : console=ttySC1,38400
Linux version 2.4.31-uc0 (root@KURO-BOXHG) (gcc version 3.4.0) #39 Sun Feb 12 14:24:23 JST 2006

uClinux H8/300H
Target Hardware: AE-3068
H8/300 series support by Yoshinori Sato <ysato@users.sourceforge.jp>
Flat model support (C) 1998,1999 Kenneth Albanowski, D. Jeff Dionne
On node 0 totalpages: 2048
zone(0): 0 pages.
zone(1): 2048 pages.
zone(2): 0 pages.
Kernel command line: console=ttySC1,38400
virtual vector at 0x00fffd20
Calibrating delay loop... 3.26 BogoMIPS
Memory available: 2392k/3085k RAM, 0k/0k ROM (813k kernel code, 194k data)
Dentry cache hash table entries: 1024 (order: 1, 8192 bytes)
Inode cache hash table entries: 512 (order: 0, 4096 bytes)
Mount cache hash table entries: 512 (order: 0, 4096 bytes)
Buffer cache hash table entries: 1024 (order: 0, 4096 bytes)
Page-cache hash table entries: 2048 (order: 1, 8192 bytes)
POSIX conformance testing by UNIFIX
Linux NET4.0 for Linux 2.4
Based upon Swansea University Computer Society NET3.039
Initializing RT netlink socket
Starting kswapd
SuperH SCI(F) driver initialized
ttySC0 at 0x00ffffb0 is a SCI
ttySC1 at 0x00ffffb8 is a SCI
ttySC2 at 0x00ffffc0 is a SCI
ne.c:v1.10 9/23/94 Donald Becker (becker@scyld.com)
Last modified Nov 1, 2000 by Paul Gortmaker
NE*000 ethercard probe at 0x200000:<4>eth0: interrupt from stopped card
00 02 cb 01 eb 1a
eth0: NE1000 found at 0x200000, using IRQ 17.
Blkmem copyright 1998,1999 D. Jeff Dionne
Blkmem copyright 1998 Kenneth Albanowski
Blkmem 1 disk images:
0: 4FC9D0-58F5CF [VIRTUAL 4FC9D0-58F5CF] (RO) <ROMFS>
Uniform Multi-Platform E-IDE driver Revision: 7.00beta4-2.4
ide: Assuming 50MHz system bus speed for PIO modes; override with idebus=xx
hda: probing with STATUS(0x50) instead of ALTSTATUS(0xff)
hda: SAMSUNG SV1203N, ATA DISK drive
hdb: probing with STATUS(0x00) instead of ALTSTATUS(0xff)
hdb: probing with STATUS(0x00) instead of ALTSTATUS(0xff)
ide0 at 0x00c00000-0x00c0000f,0x00c00020 on irq 16
hda: attached ide-disk driver.
hda: host protected area => 1
ide0: unexpected interrupt, status=0x51, count=1
hda: task_no_data_intr: status=0x51 { DriveReady SeekComplete Error }
hda: task_no_data_intr: error=0x10 { SectorIdNotFound }, LBAsect=274965953385599, high=16389247, low=1
6389247, sector=0
hda: 234493056 sectors (120060 MB) w/2048KiB Cache, CHS=14596/255/63
Partition check:
hda: hda1
NET4: Linux TCP/IP 1.0 for NET4.0
IP Protocols: ICMP, UDP, TCP
IP: routing cache hash table of 512 buckets, 4Kbytes
TCP: Hash tables configured (established 512 bind 1024)
Sending DHCP requests .., OK
IP-Config: Got DHCP answer from 0.0.0.0, my address is 192.168.1.16
IP-Config: Complete:
device=eth0, addr=192.168.1.16, mask=255.255.255.0, gw=192.168.1.1,
host=192.168.1.16, domain=, nis-domain=(none),
bootserver=0.0.0.0, rootserver=0.0.0.0, rootpath=
VFS: Mounted root (rootfs filesystem).
VFS: Mounted root (romfs filesystem) readonly.
Freeing unused kernel memory: 32k freed (0x4d6000 - 0x4dd000)
Shell invoked to run file: /etc/rc
Command: hostname AE3068
Command: mount -t proc proc /proc
Command: cat /etc/motd
Welcome to
____ _ _
/ __| ||_|
_ _| | | | _ ____ _ _ _ _
| | | | | | || | _ \| | | |\ \/ /
| |_| | |__| || | | | | |_| |/ \
| ___\____|_||_|_| |_|\____|\_/\_/
| |
|_|

Akizukidenshi/AE-3068 (aki3069net) port.
For further information check:
http://www.uclinux.org/

Execution Finished, Exiting

Sash command shell (version 1.1.1)
/> fdisk /dev/hda

The number of cylinders for this disk is set to 14596.
There is nothing wrong with that, but this is larger than 1024,
and could in certain setups cause problems with:
1) software that runs at boot time (e.g., old versions of LILO)
2) booting and partitioning software from other OSs
(e.g., DOS FDISK, OS/2 FDISK)

Command (m for help): p

Disk /dev/hda: 255 heads, 63 sectors, 14596 cylinders
Units = cylinders of 16065 * 512 bytes

Device Boot Start End Blocks Id System
/dev/hda1 1 14596 117242338+ 83 Linux

Command (m for help): q

/> mount /dev/hda1 /mnt
EXT2-fs warning: mounting unchecked fs, running e2fsck is recommended
/> ls /mnt
ae3068config.tar.gz
aki-h8
binutils-2.11.2.tar.gz
binutils-2.14.tar.gz
binutils-2.15.tar.tar
binutils-2.16.1.tar.gz
elf2flt-20030816.tar.gz
elf2flt-20050308.tar.bz2
gcc-2.95.3.tar.gz
gcc-3.3.2.tar.tar
gcc-3.4.5.tar.gz
inetutils-1.4.2.tar.gz
linux-4.bin.gz
linux-5.bin.gz
lost+found
newlib-1.14.0.tar.gz
newlib-1.9.0.tar.gz
redboot-aki3068net-1.mot.gz
redboot-aki3068net-2.mot.gz
redboot-aki3068net.mot.gz
redboot-aki368net.mot.gz
redboot.mot
redboot.mot.gz
root
sh-utils-2.0.tar.tar
tmp
userland.tar.gz
/>
